P8 Outdoor LED Display Module
৳ 15,000.00
Key Features:
-
Pixel Pitch: 8.0mm – optimized for long-range outdoor visibility
-
Module Resolution: 40×20 pixels
-
Brightness: ≥5500 cd/m² – excellent performance under sunlight
-
Size: 320mm × 160mm
-
Weatherproof Design: IP65 front / IP54 rear
-
Wide Viewing Angle: 160° H/V
-
Refresh Rate: ≥1920Hz (upgradeable to 3840Hz)
-
Maintenance: Front and rear servicing supported
-
Applications: Billboards, stadium displays, street signage, outdoor video walls
Specification:
| Parameter | Value |
|---|---|
| Module Name | LC3P Outdoor LED Display Module |
| Pixel Pitch | 8.0mm |
| LED Type | SMD2121 |
| Module Size | 320mm × 160mm |
| Module Resolution | 40 × 20 pixels |
| Pixel Density | ~15,625 pixels/m² |
| Brightness | ≥5500 cd/m² |
| Refresh Rate | ≥1920Hz (Upgradable to 3840Hz) |
| Gray Scale | 14–16 bit |
| Viewing Angle | 160° (H) / 160° (V) |
| Cabinet Material | Die-cast Aluminum / Iron (Optional) |
| Cabinet Size (Optional) | 960×960mm / 960×480mm |
| Power Input | AC 100–240V, 50/60Hz |
| Max Power Consumption | ~700W/m² |
| Avg. Power Consumption | ~230W/m² |
| Control Compatibility | Novastar / Colorlight / Huidu |
| Installation Type | Fixed / Hanging / Rental |
| Maintenance Access | Front & Rear |
| IP Rating | IP65 (Front) / IP54 (Rear) |
| Operating Temperature | -20°C to +60°C |
| Life Span | ≥100,000 hours |
Description:
The LDMO1108 – P8 Outdoor LED Display Module is an industrial-grade, high-visibility digital signage solution built for demanding outdoor environments. Featuring a pixel pitch of 8.0mm and a 40×20 resolution layout, this 320×160mm module offers an optimal balance of clarity, brightness, and cost-efficiency.
Powered by SMD2121 LEDs, the module delivers a brilliant brightness level of ≥5500 cd/m², ensuring your content remains vividly visible in direct sunlight. Its wide 160° viewing angle guarantees that advertisements or live feeds are legible from virtually any direction.
Rated IP65 at the front and IP54 at the rear, the module withstands rain, dust, and harsh climate conditions. Whether deployed in roadside billboards, stadium scoreboards, or open-air digital advertising systems, the module performs reliably with minimal maintenance.
With support for both front and rear servicing, and seamless compatibility with control systems like Novastar, Colorlight, and Huidu, integration into existing setups is simple and efficient. The LDMO1108 is ideal for long-lasting outdoor applications demanding brightness, ruggedness, and scalability.
