P1.25mm Indoor Full-Color LED Display Module
Original price was: ৳ 12,500.00.৳ 10,500.00Current price is: ৳ 10,500.00.
Key Features
- Pixel Pitch: 1.25mm
- Module Resolution: 256×128 pixels (Total 32,768 dots)
- Module Size: 320mm × 160mm
- LED Type: SMD 3-in-1 (1R1G1B)
- Scan Mode: 1/64 Constant Current
- Brightness: 600–800 cd/m²
- Refresh Rate: ≥3840Hz
- Gray Level: 14–16 bit
- Viewing Angle: 160° (Horizontal & Vertical)
- Contrast Ratio: 5000:1
- Input Voltage: DC 5V
- Average Power Consumption: 250W/m²
- Maximum Power Consumption: 580W/m²
- Warranty: 2 Years
Technical Specifications
| Feature | Specification |
| Model | LDMI1001 |
| Product Type | Indoor LED Display Module |
| Pixel Pitch | 1.25mm |
| Module Resolution | 256 × 128 pixels (Total 32,768 dots) |
| Module Size | 320mm × 160mm |
| LED Type | SMD 3-in-1 (1 Red, 1 Green, 1 Blue) |
| Color Configuration | Full Color RGB |
| Scan Mode | 1/64 Constant Current Drive |
| Brightness | 600–800 cd/m² |
| Refresh Rate | ≥3840Hz |
| Gray Scale Level | 14–16 Bit |
| Viewing Angle | 160° (Horizontal & Vertical) |
| Contrast Ratio | 5000:1 |
| Input Voltage | DC 5V |
| Average Power Consumption | 250W/m² |
| Maximum Power Consumption | 580W/m² |
| Module Weight | Approx. 0.45 kg |
| Working Temperature | -10°C to +50°C |
| Humidity Range | 10% to 90% RH (non-condensing) |
| Lifespan | ≥100,000 Hours |
| Warranty | 2 Years |
Applications
- Control Rooms & Security Monitoring
- Conference & Meeting Halls
- TV & Media Studios
- Indoor Advertising & Retail Displays
- Live Event Backdrops
- Command & Dispatch Centers
Package Contents
- 1 × LDMI1001 LED Module
- 1 × 4-Pin Power Cable
- 1 × 16-Pin Flat Data Cable
- Mounting Accessories
