LED Display Builder
P6 Outdoor LED Display Module
৳ 10,000.00
Key Features
- Pixel Pitch: 6.0mm – optimized for crisp outdoor visuals
- LED Type: SMD2121 – suitable for high brightness and weather resistance
- Module Size: 192mm × 192mm
- Module Resolution: 32 × 32 pixels
- Refresh Rate: ≥1920Hz – ensures flicker-free motion
- Brightness: ≥5500 cd/m² – clearly visible in sunlight
- Viewing Angle: 160° (H/V) – uniform clarity from all directions
- Maintenance: Front & Rear access supported
- Weather Resistance: IP65 front / IP54 rear
- Applications: Digital billboards, street displays, sports venues
Specification
| Parameter | Value |
| Module Name | LC3P Outdoor LED Display Module |
| Pixel Pitch | 6.0mm |
| LED Type | SMD2121 |
| Module Size | 192mm × 192mm |
| Module Resolution | 32 × 32 pixels |
| Pixel Density | ~27778 pixels/m² |
| Brightness | ≥5500 cd/m² |
| Refresh Rate | ≥1920Hz (Upgradable to 3840Hz) |
| Gray Scale | 14–16 bit |
| Viewing Angle | 160° (H) / 160° (V) |
| Cabinet Material | Die-cast Aluminum / Iron (Optional) |
| Cabinet Size (Optional) | 576×576mm / 768×768mm |
| Power Input | AC 100–240V, 50/60Hz |
| Max Power Consumption | ~700W/m² |
| Average Power Consumption | ~230W/m² |
| Control System Compatibility | Novastar / Colorlight / Huidu |
| Installation Type | Fixed / Hanging / Rental |
| Maintenance Access | Front & Rear |
| IP Rating | IP65 (Front) / IP54 (Rear) |
| Operating Temperature | -20°C to +60°C |
| Life Span | ≥100,000 hours |
Description
The LC3P Outdoor LED Module (192×192mm) with a 6.0mm pixel pitch is engineered for outdoor environments that demand sharp resolution and long-lasting performance. With a grid of 32×32 pixels, the module offers high-impact visuals suitable for roadside screens, building facades, and other public signage.
Its compact square size ensures modular flexibility, and the high brightness level guarantees visibility even in bright sunlight. Front and rear maintenance, along with IP-rated protection, makes it highly serviceable and durable for continuous outdoor use.
