P6.67 Indoor LED Display Module
৳ 6,000.00
Key Features
- Pixel Pitch: 6.67mm – designed for clear and reliable indoor displays
- LED Type: SMD2121 – vibrant color and reliable performance
- Module Size: 320mm × 160mm
- Module Resolution: 48 × 24 pixels
- Refresh Rate: ≥1920Hz – smooth and stable video output
- Brightness: ≥800 cd/m² – suitable for indoor environments
- Wide Viewing Angle: 160° (H/V) – clear from all directions
- Maintenance: Front & Rear access supported
- Easy Splicing Design: Seamless integration for modular displays
- Applications: Retail signage, information boards, auditoriums, conference rooms
Specification
| Parameter | Value |
| Module Name | LC3P Indoor LED Display Module |
| Pixel Pitch | 6.67mm |
| LED Type | SMD2121 |
| Module Size | 320mm × 160mm |
| Module Resolution | 48 × 24 pixels |
| Pixel Density | ~22478 pixels/m² |
| Brightness | ≥800 cd/m² |
| Refresh Rate | ≥1920Hz (Upgradable to 3840Hz) |
| Gray Scale | 14–16 bit |
| Viewing Angle | 160° (H) / 160° (V) |
| Cabinet Material | Die-cast Aluminum / Iron (Optional) |
| Cabinet Size (Optional) | 640×480mm / 960×480mm |
| Power Input | AC 100–240V, 50/60Hz |
| Max Power Consumption | ~500W/m² |
| Average Power Consumption | ~170W/m² |
| Control System Compatibility | Novastar / Colorlight / Huidu |
| Installation Type | Fixed / Hanging / Rental |
| Maintenance Access | Front & Rear |
| Operating Temperature | -10°C to +45°C |
| Life Span | ≥100,000 hours |
Description
The LC3P Indoor LED Module (320×160mm) with a 6.67mm pixel pitch is designed for applications needing clear visuals at standard viewing distances. With a calculated resolution of 48×24 pixels, it is ideal for large indoor displays in auditoriums, conference centers, and public signage.
SMD2121 LEDs deliver sharp contrast and consistent color, while the ≥1920Hz refresh rate ensures video and motion graphics play smoothly. The module supports both front and rear maintenance and works seamlessly with major control systems including Novastar and Colorlight.
It offers an optimal balance between performance, pixel clarity, and affordability for indoor display networks.
