Name: 26 Pin FRC Flat Ribbon Cable with IDC Connector - Mugnee Multiple Limited
Availability: InStock

Key Features

26 Conductors – For simultaneous multi-signal connections
Standard 2.54mm Pitch – Compatible with most development boards and headers
IDC Connector (2×13 Female) – Quick, tool-based, solder-free connection
Color-coded Flat Cable – One colored wire for pin-1 identification
Flexible, Flat Profile – Easy routing inside enclosures
Available in multiple lengths – 30cm / 50cm / 1m
Plug & Play – No soldering or crimping required

Description

Technical Specifications

Reviews (0)

The 26-pin FRC Cable is a flat ribbon-style cable used for reliable and compact multi-pin data transmission in embedded systems, industrial automation, development boards, and other digital interfaces. It includes an IDC female connector (2×13 pins), allowing easy connection to 2.54mm pitch male headers without soldering. Ideal for microcontroller interfacing, signal transfer, LCD/keypad connections, and parallel communications

Applications

Microcontroller to peripheral interface
Parallel communication (e.g., data buses)
LCD, keypad, or I/O module connections
EEPROM programmer & ISP cable wiring
Lab projects and industrial controllers
DIY embedded system development

Specification	Value
Number of Pins	26 (2 rows of 13 pins)
Pitch (Pin Spacing)	2.54mm (0.1 inch)
Connector Type	IDC Female (2x13)
Cable Type	Flat Ribbon Cable (FRC)
Color	Grey with one colored stripe for pin 1
Material	PVC Insulated
Temperature Range	Approx. -20°C to +80°C
Typical Lengths	30cm / 50cm / 1m (custom lengths available)
Wire Gauge	28 AWG (standard)
