Name: NovaStar DSP600 Pro All-in-One LED Controller
Brand: Mugnee Multiple Limited
Price: 195000.00 BDT
Availability: InStock

Specifications

Description

Reviews (0)

Specification	Details
Product Name	NovaStar DSP600 Pro
Product Type	All-in-One LED Controller
Maximum Load Capacity	3.9 Million Pixels
Maximum Output Resolution	10,240 × 8,192 Pixels
Video Input Resolution	Up to 4K × 2K @ 60Hz
Ethernet Outputs	6 × Gigabit Ethernet
Fiber Outputs	2 × Optical Fiber
HDMI Input	1 × HDMI 2.0 (IN & LOOP), 2 × HDMI 1.3
SDI Input	1 × 3G-SDI (IN & LOOP)
USB	1 × USB 3.0
HDMI Output	1 × HDMI 1.3 (Monitor)
3D Support	1 × 3D Connector
Display Layers	6 Independent Layers
Image Scaling	Stepless Scaling
Low Latency	Supported
Calibration	Pixel-Level Brightness & Chroma Calibration
Working Modes	Video Controller, Fiber Converter, ByPass
Power Supply	AC 100–240V, 50/60Hz
Power Consumption	41 W
Operating Temperature	0°C to +50°C
Operating Humidity	5%–85% RH (Non-condensing)
Storage Temperature	-10°C to +60°C
Storage Humidity	5%–95% RH (Non-condensing)
Dimensions	482.6 × 302.2 × 50.1 mm
Net Weight	3.9 kg
Total Weight	6.5 kg
Noise Level	45 dB(A)

The NovaStar DSP600 Pro All-in-One LED Controller is a high-performance LED video processor and controller that combines advanced video processing and LED display control into a single device. Designed for professional LED video walls, live events, broadcast studios, rental LED displays, command centers, and fixed installations, the DSP600 Pro delivers outstanding image quality with exceptional flexibility.

Supporting up to 3.9 million pixels and a maximum output resolution of 10,240 × 8,192 pixels, the DSP600 Pro is ideal for ultra-wide and ultra-high-resolution LED screens. It features 6 Gigabit Ethernet ports, HDMI 2.0, HDMI 1.3, 3G-SDI, 10G optical fiber, USB 3.0 playback, and dual fiber outputs for reliable signal transmission and redundancy.

The controller supports 4K×2K@60Hz video input, 6 independent display layers, stepless output scaling, low latency, pixel-level brightness and chroma calibration, and three working modes including Video Controller, Fiber Converter, and ByPass. These powerful features make the DSP600 Pro an ideal solution for demanding professional LED display applications.
