Name: NovaStar DSP400 All-in-One LED Controller
Brand: Mugnee Multiple Limited
Price: 170000.00 BDT
Availability: InStock

Specifications

Description

Reviews (0)

Specification	Details
Product Name	NovaStar DSP400
Product Type	All-in-One LED Controller
Maximum Load Capacity	2.6 Million Pixels
Maximum Output Resolution	10,240 × 8,192 Pixels
Ethernet Outputs	4 × Gigabit Ethernet
Fiber Outputs	2 × Optical Fiber
HDMI Input	1 × HDMI 1.3 (IN & LOOP), 1 × HDMI 1.3
DVI Input	1 × DVI (IN & LOOP)
SDI Input	1 × 3G-SDI (IN & LOOP)
HDMI Output	1 × HDMI 1.3
Optical Fiber	Self-adaptive Input/Output
Display Layers	2 Layers (Main + PIP)
Image Scaling	Stepless Scaling
Low Latency	Up to 20 Scan Lines
Calibration	Pixel-Level Brightness & Chroma Calibration
Power Supply	AC 100–240V, 50/60Hz
Power Consumption	28 W
Operating Temperature	0°C to +45°C
Operating Humidity	20%–90% RH (Non-condensing)
Storage Temperature	-20°C to +70°C
Storage Humidity	10%–95% RH (Non-condensing)
Dimensions	483.6 × 301.2 × 50.1 mm
Net Weight	4 kg
Noise Level	45 dB(A)

The NovaStar DSP400 All-in-One LED Controller is a professional LED display controller that combines advanced video processing and LED control into a single device. Designed for fixed LED installations, rental LED displays, broadcasting, command centers, conference rooms, and digital signage, the DSP400 delivers outstanding image quality and reliable performance.

Supporting up to 2.6 million pixels, the DSP400 offers a maximum output resolution of 10,240 × 8,192 pixels, making it suitable for ultra-wide and ultra-high-resolution LED screens. Equipped with HDMI, DVI, 3G-SDI, optical fiber, Gigabit Ethernet, and HDMI output, it provides flexible connectivity for a wide range of professional applications.

Powered by NovaStar’s SuperView III image processing technology, the DSP400 features low latency, stepless scaling, pixel-level brightness and chroma calibration, HDR-quality image enhancement, free input cropping, multi-layer display, hot backup, and automatic brightness adjustment. Whether used as a video controller, fiber converter, or bypass device, the DSP400 ensures stable and high-quality LED display performance.
